100 ET HT UT Stainless Steel Seamless Pipe For Heat Exchanger Air Cooler Condenser

Brand Name : HDT

Model Number : TP304/304L , TP316L , TP310S, TP316Ti, TP321/321H , TP347 , TP317

Certification : ASME, TUV, SGS, ABS, PED, ISO9001, Grade A

Place of Origin : China(Mainland)

MOQ : 5T

Price : 800 - 9000 USD / ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : About 10000 ton / month

Delivery Time : 60-75days

Packaging Details : seaworthy packing for exporting

Material : TP304/304L , TP316L , TP310S, TP316Ti, TP321/321H , TP347 , TP317

Finishing : Solution Annealed & Pickled

Application : boiler&heat exchanger, Condenser, energy, petrochemical, mining, gas and fluid industry

Shape : round seamless

OD : 6.00mm to 850mm

WT : 0.5mm to 68mm

Contact Now

Heat Exchanger ( Intercambiador de calor ) Air Cooler Condenser Seamless Tube 100 ET / HT / UT

Specification:

ASME SA213/A213: Standard Specification for Seamless Ferritic and Austenitic Alloy-

Steel Boiler, Superheater and Stainless Steel Heat Exchanger Pipes.

ASTM A249 / A249M:Standard Specification for Welded Austenitic Steel Boiler, Superheater

Heat-Exchanger, and Condenser Pipes.

ASTM A789/A789M, ASME SA789/SA789M Seamless and Welded Ferritic/Austenitic Stainless Steel Piping for General Service

Other Standard:DIN 17456 , DIN 17458, EN10216-5, GOST 9940-81, GOST 9941-81, JIS-G3463,...

Material Grade:

American Standard

Austenitic Steel:

TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…

Duplex Steel :

S32101,S32205,S31803,S32304,S32750, S32760

Others:TP405,TP409, TP410, TP430, TP439,...

Europen Standard

1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501

Russia Standard

08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ

Size Range:

Production	Outside Diameter	Wall Thickness
Heat Exchanger Tube	6.00mm to 850mm	0.5mm to 68mm

Final Finishing

Solution Annealed & Pickled/Bright Annealed.

Type of pipes:

U-bend & Straight.

Some of the quality tests carried out by us includes:

Corrosion Test	Conducted only when specially requested by the client
Chemical Analysis	Test done as per required quality standards
Destructive / Mechanical Testing	Tensile \| Hardness \| Flattening \| Flare \| Flange
Reverse-bend and Re. flat tests	Carried out in full compliance with relevant standards & ASTM A-450 and A-530 norms, which ensures trouble-free expansion, welding & use at customers end
Eddy Current Testing	Done to detect homogeneities in subsurface by using Digital Flaw-mark Testing System
Hydrostatic Testing	100% Hydrostatic Testing carried out according to ASTM-A 450 norms for checking tube leakage, and biggest pressure we can support 20Mpa/7s .
Air Under Pressure Test	To check any evidence of air leakage
Visual Inspection	After passivation, every single length of tubes & pipes is subjected to thorough visual inspection by trained staff for detecting surface flaws & other imperfections

Supplementary Testing : Apart from the above mentioned tests, we also carry out on the manufactured products supplementary testing. The tests conducted under this include:

Eddy Current Testing
O.P Testing
Radiography Testing

Corrosion Testing
Micro Testing
Macro Testing

IGC Testing
Ultrasonic testing
Liquid Penetrate testing

100 ET HT UT Stainless Steel Seamless Pipe For Heat Exchanger Air Cooler Condenser

Certification

100 ET HT UT Stainless Steel Seamless Pipe For Heat Exchanger Air Cooler Condenser
